Artifact: Regulator Assembly, Helium Pressure, Reaction Control, Apollo Service Module, Block II

Bookmark and Share
Identifier: A20120044
Artifact Category: Rocket Propulsion Systems
Period of Employment: October 11 1968 to July 24 1975
Manufacturer: Fairchild Stratos Corp
NASA Contract Number: NAS9-150
Spacecraft/Launch Systems: Apollo Service Module
Materials:

Stainless Steel, Aluminum

Dimensions: 6.5 x 2,5 x 5 (Inches)
Weight: 2.5 Pound (estimated)
Flight Vehicle System or Component: Reaction / Reentry Control (RCS),Propellant Pressurization
Program: Apollo
Flown Status: Unflown
Description:

Reaction Control System (RCS) Helium Pressure Regulator assembly manufactured by Fairchild Stratos Corp (Western Division) for the Apollo Service Module (Service Propulsion System), Reaction Control System pressurization system under NASA contract NAS9-150 for North American Aviation (NAA). The dual, series configured regulators (produced 1965) received gas from the SPS helium tank isolation valve and reduced ambient tank pressure of 4150 PSIA to approx 220 PSIA (nominal) before forwarding to the downstream RCS check valve (see RCS Check Valve description which precedes this entry). Each assembly incorporates two (primary and secondary) regulators connected in series. If the primary regulator fails open, the secondary regulator will maintain slightly higher but acceptable pressures. Diagram to the left depicts functional relationship/location of regulator in the RCS system.
